Type
Compact Digital Camera
-
Effective Pixels
12.2 million
-
Image Sensor
CCD
-
Sensor Size
1/2.3 in.
-
Total Pixels
12.39 million (approx.)
-
Lens Focal Length
5.0-25.0mm (angle of view equivalent to that of 28-140mm lens in 35mm [135] format)
-
Lens f/-number
f/2.7-6.6
-
Lens Construction
7 elements in 6 groups
-
Lens Zoom
5x
-
Lens Specification
5.0-25.0mm (35mm [135] format picture angle: 28-140mm); f/2.7-6.6
-
Digital Zoom
Up to 2x (angle of view equivalent to that of 280mm lens in 35mm [135] format)
-
Vibration Reduction
Lens-shift VR
-
Autofocus (AF)
Contrast-detect AF
-
Autofocus (AF) Focus-area selection
Auto (9-area automatic selection)
Center
Face priority
Manual with 99 focus areas
-
Focus Range
[W]: Approx. 1 ft. 6 in. (45 cm.) to infinity
[T]: Approx. 2 ft. 4 in. (70 cm.) to infinity
Macro close-up mode: Approx. 0.8 in. (2 cm.) to infinity
-
Focus Lock
Yes
-
Monitor Size
2.7 in. diagonal
-
Monitor Type
TFT-LCD with Anti-reflection coating
5-level brightness adjustment
-
Monitor Resolution
230,000-dots
-
Monitor Frame coverage (shooting mode)
100% horizontal (Approx.)
100% vertical (Approx.)
-
Monitor Frame coverage (playback mode)
100% horizontal (Approx.)
100% vertical (Approx.)
-
Storage Media
SD memory card
SDHC memory card
32MB internal memory (approx.)
Not compatible with Multi Media Cards (MMC).
-
Storage File System
DCF
EXIF 2.2
DPOF compliant
-
Movie
Audio file format: monaural
HD: 1280x720p / 30fps
Movie file format: AVI Motion JPEG compliant
Small Size: 320x240 / 30fps
Standard TV: 640x480 / 30fps
-
Image Size (pixels)
3264 x 2448 (8M)
4000 x 3000 (12M)
2592 x 1944 (5M)
2048 x 1536 (3M)
1024 x 768 (PC)
640 x 480 (VGA)
3968 x 2232 (16:9)
Unless otherwise stated, all figures are for a camera with a fully-charged Rechargeable Li-ion Battery EN-EL10 operated at an ambient temperature of 25 °C (77 °F).
-
ISO Sensitivity
ISO 100-3200
Auto (auto gain ISO 100-1600)
Fixed range auto (ISO 100-400, 100-800)
-
Exposure Metering
224-segment matrix, center-weighted
-
Exposure Control
Programmed auto exposure with motion detection
Exposure compensation (-2.0 to +2.0 EV in steps of 1/3 EV)
-
Exposure Range (auto mode)
[W]: -1.1 to +16.4 EV
[T]: 1.5 to 19 EV
(exposure values achieved with automatic ISO sensitivity adjustment converted to ISO 100 values)
-
Shutter
Mechanical and charge-coupled electronic shutter
-
Shutter Speed
1/1500-1 sec. (when ISO sensitivity is set to Auto, 1600, 3200)
1/1500-2 sec. (when ISO sensitivity is set to 800)
1/1500-8 sec. (when ISO sensitivity is set to 100, 200, 400)
4 sec. (when scene mode is set to Fireworks show)
Unless otherwise stated, all figures are for a camera with a fully-charged Rechargeable Li-ion Battery EN-EL10 operated at an ambient temperature of 25 °C (77 °F).
-
Top Continuous Shooting Speed at full resolution
Up to 10 shots at approx. 0.7 frames per second
-
Aperture
Electronically-controlled ND filter (-3 AV) selection
-
Aperture Range
2 steps (f/2.7 and f/7.6 [W])
-
Self-timer
Can be selected from 10 and 2 seconds duration
-
Built-in flash Range (approx.) (ISO sensitivity: Auto)
[W]: 0.5 to 6.0m (1ft. 8in. to 19ft.)
[T]: 0.7 to 2.5m (2ft. 4in. to 8ft.)
-
Built-in Flash Control
TTL auto flash with monitor preflashes
-
Interface
Hi-speed USB
-
Interface Data transfer protocol
MTP
PTP
-
Video Output
NTSC
PAL
-
I/O terminal
Audio/video (A/V) output
Digital I/O (USB)
-
Supported Languages
Arabic
Czech
Chinese (Simplified and Traditional)
Danish
Dutch
English
Finnish
French
German
Greek
Hungarian
Indonesian
Italian
Japanese
Korean
Norwegian
Polish
Portugese
Russian
Spanish
Swedish
Thai
Turkish
-
Power Sources
One Rechargeable Li-ion Battery EN-EL10 (supplied)
AC Adapter EH-62D (available separately)
-
Charging Time
3 hours (when using Charging AC Adapter EH-68P and when no charge remains) (Approx.)
-
Battery / Batteries
Rechargeable Li-ion Battery EN-EL10
-
Battery Life (shots per charge)
Still pictures*: Approx. 200 shots
Movies: Approx. 1h 40min. (HD 720p)
*Based on Camera and Imaging Products Association (CIPA) standards for measuring the life of camera batteries. Measured at 23(±2)°C (73(±4)°F); zoom adjusted with each shot, flash fired with every other shot, image mode set to 4000 × 3000.
*Battery life may vary depending on shooting interval and length of time menus and images are displayed.
-
Tripod Socket
¼-20
-
Approx. Dimensions
Height: 2.3in. (56.9mm)
Width: 3.9in. (97.1mm)
Depth: 0.9in. (21.6mm)
Excluding projections.
Method of noting dimensions and weight is in accordance with CIPA DCG-005-2009 guideline.
-
Approx. Weight
4.7 oz. (132.0g)
with battery and SD memory card.
Method of noting dimensions and weight is in accordance with CIPA DCG-005-2009 guideline.
-
Operating environment
Temperature: 0 to 40°C (32 to 104°F)
Humidity: Less than 85% (no condensation)
-
Supplied Accessories
- AN-CP19 Strap
- EN-EL10 Rechargeable Battery
- UC-E6 USB Cable
- EG-CP14 Audio Video Cable
- Software Suite CD-ROM
